With its intuitive layout, extensive features and I/O and PreSonus®' famed sound quality, the Monitor Station V2 provides a versatile, convenient and affordable solution for managing your studio monitoring system from your desktop. Switch quickly and easily between up to four audio sources, including two pairs of balanced ¼-inch inputs and a third input channel that can be fed from an S/PDIF digital input (up to 96 kHz), unbalanced RCA Aux inputs with gain control and a ⅛-inch TRS unbalanced input. A button switches between the analog Aux and digital S/PDIF inputs.
Couldn't load pickup availability
We’re celebrating the launch of our new website. Get $20 off when you spend $1,000 or more. Discount is automatically applied at checkout.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Monitor Station V2 Monitoring Controller
Features
- 2 Stereo pairs of ¼-inch TRS inputs, 1 Stereo pair of RCA Aux inputs with level control and 1 Stereo S/PDIF coaxial (RCA) digital input (44.1/48/88.2/96 kHz)
- 3 Stereo pairs of ¼-inch TRS speaker outputs with level controls, 1 Stereo pair of ¼-inch TRS Main outputs and 1 Stereo pair of ¼-inch TRS Cue outputs
- 4 ¼-inch TRS screaming-loud stereo headphone outputs
- Large Main level control
- 3 Individual Main Source (ST1, ST2, Aux) select switches
- 3 Individual Speaker Select switches
- Cue section with Source select (ST1, ST2, Aux) and output-level control
- Main Mute, Mono, and Dim switches with variable Dim attenuation
- 8-segment color LED input meters with selectable reference level
- Built-in electret-condenser talkback microphone with input-gain control and Talkback button
Additional controls.
The Monitor Station V2 offers many features to customize your monitoring system. A Mono switch sums the stereo outputs to check for phase problems. A large knob controls the main speaker output level (but not the main line-level outs), and a Dim switch lets you reduce the speaker output by a variable amount. You can mute the speakers as well.
Specs |
|
Accessories |
|
| Footswitch | NA |
Electronics |
|
| VoltageRequirements | 100-240 VAC, 50-60 Hz |
General |
|
| Color | Black |
| Product Name | Monitor Station V2 Monitoring Controller, Black |
| Series | Monitoring Controllers |
Hardware |
|
| Microphone Types | Electret Condenser |
| SPDIF Connection Type | RCA 75Ω Coax |
| Speaker Output Connection Type | 1/4" |
Inputs |
|
| Auxiliary Input Connection Type | RCA Active, Unbalanced |
| Auxiliary Input Frequency Response | 10 Hz to 50 kHz |
| Auxiliary Input Gain Range | 80 dB to +10 dB |
| Auxiliary Input Impedance | 47.5 kΩ |
| Auxiliary Input Signal To Noise Ratio | >115 dB |
| Auxiliary Input Total Harmonic Distortion | <0.01% |
| Line Input Connection Type | 1/4" TRS, Balanced |
| Line Inputs Frequency Response | 10 Hz to 65 kHz |
| Line Inputs Impedance | 10 kΩ |
| Line Inputs Maximum Level | +22 dBu |
| Line Inputs Signal To Noise Ratio | >105 dB |
| Line Inputs Total Harmonic Distortion | <0.0075% |
Measurements |
|
| Product Depth | 8.5" (21.6 cm) |
| Product Height | 2.5" (63.5 mm) |
| Product Height/Length | 2.5" (63.5 mm) |
| Product Width | 9" (22.9 cm) |
Miscellaneous |
|
| Power Cable | External DC Transformer/Internal Line, 18 VDC |
Output |
|
| Cue Output Connection Type | 1/4" |
| Cue Output Dim Attenuation | -20 dB (Talkback Activated) |
| Cue Output Gain Range | -80 dB to 0 dB |
| Headphone Outputs Frequency Response | 10 Hz to 50 kHz |
| Headphone Outputs Maximum Output | 150 mW / channel |
| Main And Line Outputs Frequency Response | 10 Hz to 50 kHz |
| Main And Line Outputs Output Impedance | 51Ω |
| Main And Line Outputs Total Harmonic Distortion | <0.01% |
| Main Outputs Connection Type | 1/4" TRS, Balanced |
| SPDIF Maximum Output | +18 dBu |
| SPDIF Total Harmonic Distortion | 0.0025% (1 kHz @ -1 dBFS) |
Performance |
|
| Microphone Gain Range | +15 to +55 dB |
| Microphone Sensitivity | -42 dB |
| SPDIF Supported Sample Rates | 44.1, 48, 88.2, 96 kHz |
Speakers |
|
| Speaker Output Dim Attenuation | -30 dB to -6dB |
| Speaker Output Main Level Range | -80 dB to 0 dB |
| Speaker Output Trim Range | -80 dB to 0 dB |
