The GT-1B gives bass players a massive range of pro tone-shaping power in a small and robust package. Backed by BOSS's flagship sound engine, you have full access to a huge selection of bass-optimized amps and effects for stage and studio playing. The streamlined interface lets you dial in sounds fast, while the onboard control switch and expression pedal enable you to adjust multiple effects in real time. And by connecting to BOSS TONE CENTRAL, you can download new patches, editing software, and more. Compact, rugged, and battery powered, the GT-1B is the ultimate mobile tone companion for every bassist.
Features
Flagship-class BOSS sound engine specially tuned for bass
Pro-level amps and effects in a light, compact floor unit
Essential tools on board for optimizing your core bass tone
Includes advanced MDP effects for maximum musical expression
Modern design with no hard edges enables safe transport in an instrument bag
Easy Select and Easy Edit functions for quickly choosing and tweaking patches
Four AA batteries provide approximately seven hours of mobile playing time
Onboard control switch and expression pedal; footswitch/expression pedal jack and USB
Download pro patches and editor software for free at BOSS Tone Central (to be available in September 2017)
Specifications
Sampling Frequency: 44.1 kHzAD
Conversion: 24 bits + AF method
*AF method (Adaptive Focus method) is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.
DA Conversion: 24 bits
Effects: 90 types
Patches: 99 (User) + 99 (Preset)
Phrase Loop: 32 sec.
Nominal Input Level: INPUT: -10 dBu, AUX IN: -20 dBu
Maximum Input Level: INPUT: +7 dBu, AUX IN: 0 dBu
Input Impedance: INPUT: 1 M ohm, AUX IN: 27 k ohms
Nominal Output Level: OUTPUT (L/MONO, R): -10 dBu, PHONES: -10 dBu
Output Impedance: OUTPUT (L/MONO, R): 1 k ohm, PHONES: 44 ohms
Recommended Load Impedance: OUTPUT (L/MONO, R): 10 k ohms or greater, PHONES: 44 ohms or greater
Controls
DOWN switch, UP switch CTL1 switch
EASY SELECT button, EASY EDIT button, FX1/LIMITER button, OD/DS button, PREAMP button, FX2/MOD button, DELAY button, REVERB button, MEMORY EDIT button, EXIT button, ENTER button, MENU button
1 knob, 2 knob, 3 knob
Expression pedal
Display: Graphic LCD (132 x 32 dots, backlit LCD)
Connectors
INPUT jack, OUTPUT (L/MONO, R) jacks: 1/4-inch phone type
CTL2, 3/EXP2 jack: 1/4-inch TRS phone type
AUX IN jack: Stereo miniature phone type
USB COMPUTER port: USB type B
DC IN jack
Power Supply: Alkaline battery (AA, LR6) x 4, AC adaptor (sold separately)
Current Draw: 200 mA
Expected battery life under continuous use: Alkaline: Approx. 7 hours
*These figures will vary depending on the actual conditions of use.
Accessories
Owner's manual
Leaflet "USING THE UNIT SAFELY"
Alkaline battery (AA, LR6) x 4
Size and weight
Dimensions (W x D x H): 305 x 152 x 74 mm (12-1/16 x 6 x 2-1/4 inches)
Maximum height: 74 mm (2-15/16 inches)
Weight (including battery): 1.3 kg (2 lbs 14 oz)
