Radial - Pro48 Active Direct Box
Active Direct Box
Couldn't load pickup availability
We’re celebrating the launch of our new website. Get $20 off when you spend $1,000 or more. Discount is automatically applied at checkout.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Exceptional sonic performance
The Pro48's innovative internal switching power supply significantly increases headroom producing less distortion while yielding a smooth, linear response that extends from 20Hz to well above 40kHz. This results in natural, uncolored signal that is as good or better than DI boxes costing several times more. The superior performance makes the Pro48 an ideal candidate for use with battery powered active basses and acoustic guitars that tend to overload other direct boxes.https://www.youtube.com/watch?v=Mhc2RyaEczM
Features
- Huge internal rail voltage for extra headroom
- Ultra-flat frequency response from 20Hz to 40kHz
- High 220k input impedance reduces loading
- Plug and play simplicity for quick deployment
Applications
- Perfectly suits acoustic guitars and basses
- Provides extra 'reach' and 'air' in your sound!
- Pad switch lets you use with active instruments
- Equally wonderful for live touring or in the studio
Cool stuff
- Handles extreme transients without distortion
- No batteries required, works with phantom-power
- Ground lift reduces hum and buzz caused by ground loops
- Compact and rugged design for on the road
Pro48 Applications
Using the Pro48 with acoustic guitar
The Pro48 is the perfect interface for acoustic guitar on stage. The high internal rail voltage is able to handle the dynamics of today's active instruments without choking and deliver the smooth, natural sound of the instrument.Using the Pro48 with bass
Whether you use an active or passive bass, the Pro48's exceptional signal handling is able to capture the sound of the instrument without distortion or adding artifact. And with proper loading, your bass will sound round and smooth when you record or play live.Using the Pro48 with acoustic instruments
With more headroom and less distortion the Radial Pro48 is a great all-round active direct box for instruments of all types. This makes it particularly effective with instruments that can sound 'peaky' or 'edgy' when amplified.
Specifications |
|
| Audio circuit type: | Proprietary analog circuit with low-noise op-amp |
| Frequency response: | 20Hz ~ 20kHz (± 1.5 dB |
| Dynamic range: | 99dB |
| Total harmonic distortion: | 0.001% @ 0 dBu |
| Intermodulation Distortion: | 0.002% @ 0 dBu |
| Phase Deviation: | +28º at 20Hz | +1º at 1kHz | -2º at 20kHz |
| Input Impedance: | 220kΩ - ¼" input |
| Output Impedance: | 175Ω - XLR output |
| Equivalent Input Noise: | -86dBu |
| Noise Floor: | -82dB below 0dBu |
| Maximum Input: | +9dBu |
Features |
|
| Input pad, Ground lift | |
General |
|
| Construction: | 14-gauge steel |
| Size (L x W x D): | 4.25" x 2.75" x 1.75" (108 x 70 x 44mm) |
| Weight: | 1.2 lb (0.54kg) |
| Power: | 48V phantom - proprietary digital switching |
| Conditions: | For use in dry locations only between 5°C and 40°C |
| Warranty: | Radial 3-year, transferable |
